eVoomXT

  • Integrated 30mA AC & 6mA DC RCD
  • Built in Open PEN Fault Protection
  • RFID Enabled
  • 4G, Wi-Fi, Ethernet and Bluetooth Connectivity
  • Over-the-Air Firmware Updates
  • Scheduled & Energy Tariff Charging Options
  • Safe Electrical Load Management
  • OCPP 1.6J compliant for Remote Management & Control
  • 5-Year Warranty
Manufacturer: Commercial
£0.00
Product Specifications
Attribute name Attribute value
Product Information
Model eVoomXT
Product Number EVC7005
Connection Capacity Single Phase, 7.4kW & Three Phase , 22KW AC
Charging Connector Un-tethered, IEC 62196/Type 2
Charging Protocol Mode 3 (EN/IEC61851)
Communication
Status Indication / HMI Touch Screen & Multi-colour LEDs
Standard WiFi 802.11b/g/n @ 2.4GHz; Ethernet; Bluetooth; 4G; RS485
Physical Properties
Dimensions (H xWx D) 335mm x 187mm x 85mm
Mounting Type Pole/Wall mounted
Colour Grey
Unit Material PC
Environmental Properties
Operating Temperature -40 to +55° C
Operating Humidity Up to 95%RH, non-condensing
IP Rating IP54, IK10
Standards & Compliance
EMC Compliance EN61000-6-3:2006, EN61000-6-2:2019
Safety Compliance EN 60950-1:2006 + A11 + A1, EN60950-22:2006, BS7671:2018 + A2:2022
EV Charging Compliance EN61851-1:2019, EN61851-21:2002, EN61851-22:2002, IEC62196-1
Electrical Properties
AC Charging Output 7.4kW, 32A@230V AC & 22kW, 32A@400V AC
Input Voltage 230V AC & 400V AC nominal
Input Frequency 50 Hz
Input Current (max) 32 A
Energy Monitoring Power and energy monitoring as standard via APP & LCD display
Overcurrent Protection Internal overcurrent protection
Installation
PEN Fault Protection Built-in open PEN protection (detection + isolation). Can safely be installed without an earth-rod
RCD Protection Integrated 30mA AC and 6mA DC RCD
Service Fuse Protection Automated load management via wired CT and MID meter (available seperately)
MID Meter Inbuilt +/- 1%
